OBD Live GPS Vehicle Tracker

OBD Live GPS Vehicle Tracker simply plug the unit into the car’s OBD port and you’re ready to track. The OBD port provides uninterrupted power to your tracking device so you’ll never have to worry about losing sight of your vehicle due to a dead battery.

  • null Quad-band GSM/GPRS frequencies 850/900/1800/1900 MHz
  • null Internal superior sensitivity U-blox 7 chipset
  • null OBDII connectivity, easy to install
  • null Internal 3-axis accelerometer for motion detection and driving behavior analysis
  • null Build-in backup battery with long standby time
  • null Internal GSM/GPS antenna
  • null Wide operating voltage range 9V to 36V DC

Description

OBD Live GPS Vehicle Tracker

wide input voltageWide Input Voltage
With working voltage ranging from 9-36V could work both car and truck

Drop Off AlarmEasy To Operate
Free installation no wiring harness simply plug into vehicle OBD port

Low Battery Alarm|Vehicleknight GPS Tracking SystemLow Voltage Alarm
When the battery voltage drops below threshold an alert will sent to owner

Multiple Alarms|Vehicleknight GPS Tracking SystemMulti-Alarm
Shock alarm, move alarm, geofence alarm, over the speed Alarm, plug out alarm

BD02 Anti Theft GPS Vehicle Car Tracker

Specifications

GSM Specifications
Communication System: GSM
GSM Frequency: 850/900/1800/1900MHz
GPRS: Class 12, TCP/IP
GPS Specifications
GPS Chip: Compatible with u-blox/BDS
Channel: 66
Location Accuracy: <10meters
Tracking Sensitivity: -163dBm
Acquisition Sensitivity: -148dBm
GPS Location time: Cold Start<29s(open sky)Hot Start<1s(open sky)
Product Specifications
 GSM/GPS antenna:  Built-in quad band GSM antenna, GPS ceramic antenna
LED Indicator: One light indicate GSM/GPRS/GPS status
Work Voltage:  DC9-36V
Work Current:  ≤50mA
Standby Current: ≤3.5mA
Operating Temperature: -20℃ ~+70 ℃
Built-in Battery: 95mAh/3.7V  Industrial grade lithium polymer battery
Device Dimension: 25.1(W)*45.2(L)*32(H)mm
Device Weight: 28g
